WIND ENERGY

* Small Wind Turbine Power Curve evaluation System:

a) PWRC2 / INTI - Neuquén (Recent version 2012 a 2015) Download PDF (4.2MB, Spanish)

Photo2 - PWRC2 Systems Installed in SWT Test Site Cutral-Co / INTI

PWRC2 and INTI TestSite related publications a.1) ASADES 2013 - Power Curve (Spanish)
a.2) ASADES 2013 - PWRC2 Uncertainty Evaluation (Spanish)
a.3) INTI Small Wind Turbine Test Site (Cutral-Co/Neuquen)

Photo3 - PWRC2 preparing for maintenance / System Installed at SWT Test Site Cutral-Co / INTI (10-2015)

b) Legacy PWRC System used at PERMER (with UNPA &CREE - Centro Regional de Energía Eolica). Version PWRC (2007) PDF

ATMega PWRC System with SD card Storage

Current and Voltage sensor assembly

* L&R integrates with DM Energías Renovables for design, installation and maintenance of wind battery-charging and solar systems.

Photo - Wind - Diesel instalation by DM E-R for Petrobras Energía 2008

* LyR Ingeniería integrates with DM Energías Renovables for the design, installation and maintenance of clean energy systems in South Patagonia - See PDF (spanish).

Legacy EM/12 DC Energy meter for 12V systems. Download PDF (Sp)

* Weak-Grid Control Systems for Wind Power. For Studies and Design contact us.

* Small Systems Layout

Bergey 1.5kW/48V system, for cathodic protection, using C3b Converter from L&R Ingeniería

Eolux home system control center with 2kW Inverter (48Vdc to 220Vac/50Hz) and Regulator.

A: 2kW Inverter 2kW - B: Regulator - C: 3-Phase Rectifier

D: Fuses - E: Dump Load Resistor
